H&R Trak+ 12mm DR Wheel Adaptor Bolt 5/112 Center Bore 66.5 Bolt Thread 12x1.5

All DR-Systems require longer wheel bolts. These must be ordered separately. H&R Wheel Spacer Bolts are listed here. When ordering wheel bolts, please follow these guidelines: a) If possible, name the brand of wheel. b) New bolts must be longer than the original bolts by the width of the wheel spacer used. c) The bolt head must be identical to the existing bolt: Taper 60 End digit 01 Round head for M12/d24 mm, for M14/d28 mm End digit 02 Round head for M12/d26 mm (e.g. OE VAG-wheels) End digit 03 Flat head for Porsche original wheels M14 x 1.5 End digit 06 d) Safety guidelines (Minimum number of turns for wheel bolts / nuts): M12 x 1.25 = 8.0 turns = approx. 10 mm of load bearing shaft length M12 x 1.50 = 6.5 turns = approx. 10 mm of load bearing shaft length M12 x 1.75 = 6.5 turns = approx. 12 mm of load bearing shaft length M14 x 1.25 = 9.0 turns = approx. 12mm of load bearing shaft length M14 x 1.50 = 7.5 turns = approx. 12 mm of load bearing shaft length 1/2" UNF = 8.0 turns = approx. 11 mm of load bearing shaft length e) Please ensure that the wheel bolts do not damage any part of the brake system (ABS sensors, etc.). Turn the wheel by hand and check clearance on the inside of the hub. The wheel should rotate freely. (Maximum tolerance for some vehicles is only 2mm -- i.e. Rear Axle Mercedes).

This Part Fits:

Year	Make	Model	Submodel
2002-2005	Mercedes-Benz	C230	Kompressor
2006-2007	Mercedes-Benz	C230	Sport
2003-2005	Mercedes-Benz	C240	4Matic
2001-2005	Mercedes-Benz	C240	Base
2002-2004	Mercedes-Benz	C32 AMG	Base
2003-2005	Mercedes-Benz	C320	4Matic
2001-2005	Mercedes-Benz	C320	Base
2005-2006	Mercedes-Benz	C55 AMG	Base
2005-2013	Mercedes-Benz	CL600	Base
2008-2013	Mercedes-Benz	CL63 AMG	Base
2005-2006,2008-2013	Mercedes-Benz	CL65 AMG	Base
2003-2005	Mercedes-Benz	CLK320	Base
2006	Mercedes-Benz	CLK350	Base
2003-2006	Mercedes-Benz	CLK500	Base
2003-2006	Mercedes-Benz	CLK55 AMG	Base
2007-2009	Mercedes-Benz	CLK550	Base
2015-2017	Mercedes-Benz	CLS400	4Matic
2015-2017	Mercedes-Benz	CLS400	Base
2006	Mercedes-Benz	CLS500	Base
2006	Mercedes-Benz	CLS55 AMG	Base
2012-2018	Mercedes-Benz	CLS550	4Matic
2007-2018	Mercedes-Benz	CLS550	Base
2014	Mercedes-Benz	CLS63 AMG	4Matic
2007-2013	Mercedes-Benz	CLS63 AMG	Base
2003-2005	Mercedes-Benz	E320	4Matic
2003-2005	Mercedes-Benz	E320	Base
2007-2009	Mercedes-Benz	E320	Bluetec
2005-2006	Mercedes-Benz	E320	CDI
2006-2009	Mercedes-Benz	E350	4Matic
2006-2009	Mercedes-Benz	E350	Base
2005-2006	Mercedes-Benz	E500	4Matic
2005-2006	Mercedes-Benz	E500	Base
2007-2009	Mercedes-Benz	E63 AMG	Base
2006	Mercedes-Benz	S350	Base
2012-2013	Mercedes-Benz	S350	Bluetec 4Matic
2007-2013	Mercedes-Benz	S550	4Matic
2007-2013	Mercedes-Benz	S550	Base
2005-2013	Mercedes-Benz	S600	Base
2008-2013	Mercedes-Benz	S63 AMG	Base
2003-2006	Mercedes-Benz	SL500	Base
2004-2008	Mercedes-Benz	SL55 AMG	Base
2003	Mercedes-Benz	SL55 AMG	Kompressor
2007-2009,2011-2020	Mercedes-Benz	SL550	Base
2004-2009	Mercedes-Benz	SL600	Base
2009,2011-2012	Mercedes-Benz	SL63 AMG	Base
2005-2009,2011	Mercedes-Benz	SL65 AMG	Base
2009	Mercedes-Benz	SL65 AMG	Black Series
2006-2008	Mercedes-Benz	SLK280	Base
2005-2011	Mercedes-Benz	SLK350	Base
2005-2010	Mercedes-Benz	SLK55 AMG	Base
